The DVB T2&S2 Combo multi-media tv receiver allows user to set up the satellite channel search(DVB-S2) nd terrestrial channel search(DVB-T2).
First of all, we introduce the Satellite Channel Search Operation (DVB-S2):
Press MENU button bring up the main MENU and move cursor down to Installation, then select DVBS2 option. The system will enter below interface. There are 5 options available for different settings. 1. Antenna Setting: Please follow the screen hints to finish corresponding setting on each option: LNB Type, LNB Frequency, Transponder, 22KHz, LNB Power, Tone Burst Mode, DiSEqC Mode and DiSEqC 1.0. After finished above setting, USER could search channel by below options:Option1: set single Stellite Search by press Red color button, the STB will enter next interface, finish corresponding setting on Polarisation, Network Search, Channel Type, Scan Type, Scan Type, then press OK button to enter next interface and STB will start Scan, please wait till the scanning is finished.Option2: (1) set multi Satellite Search by press Blue color button, then STB will enter the Satellite List interface. (2) select multi satellites on the Satellite list, then press Blue(Scan) button, the STB will enter next interface.(3) finish corresponding setting on Polarisation, Network Search, Channel Type, Scan Type. (4) press OK button to enter next page and STB will start Scan, then wait till the scranning is finished. Option3: set single TP Search by press Green color button.Option4: set multi TP Search by press Yellow color button. 2. Satellite List:Follow this operating sequence Main MENU — Installation — DVBS2 — Satellite List. Functions Introduce:Add Satellite: press the Red button can add new Satellite and edit its information;Edit Satellite: press the Green button to open the Edit menu, you can modify satellite name, longitude direction and size.Delete Satellite: press the Yellow button or Del button to enter Delete status. How to scan DVB T2&S2 Combo digital box Satellite signal?Step1: finish necessary Antenna Setting firstly, then select one or multi satellites on the satellite list.Step2: press the Blue button to enter the Scan menu. Step3: finish corresponding settings on Polarisation, Network Search, Channel Type, Scan Type.Step4: press OK button to enter next interface and STB will start Scan, then wait till the scanning is finished. 3. Transponder List: SAT: press this SAT button can sellect/change the satellite.Add TP: press RED color button can add satellite, and edit the Frequency/Symbol Rate/Polarisation value of the Satellite. Edit TP: press the Green button to enter the TP edit interface, you can edit the Frequency/Symbol Rate/Polarisation of the Transponder. Delete TP: move the cursor to the specific TP, then press the Yellow button to enter the TP delete interface, choose OK, then the TP will be deleted. If you want to scan Transponder:Step1: finish necessary Antenna Setting, then select the TP on the Transponder List.Step2: press the Blue botton to enter the TP Scan MENU. Step3: finish corresponding settings on Network Search and Channel Type.Step4: press OK button to enter next page and STB will start Scan, then wait till its finished.
